SDVC35-S Variable Frequency Vibratory Feeder Controller SDVC35S:1.5A

  • SDVC35-S Variable Frequency Vibratory Feeder Controller
  • SDVC35-S Variable Frequency Vibratory Feeder Controller
  • SDVC35-S Variable Frequency Vibratory Feeder Controller
  • SDVC35-S Variable Frequency Vibratory Feeder Controller
  • SDVC35-S Variable Frequency Vibratory Feeder Controller
  • SDVC35-S Variable Frequency Vibratory Feeder Controller
Item Code:SDVC35S:1.5A Features:Model:SDVC35-S:1.5A SDVC35-M:3.0A Features: Frequency Tracking: Synchronize output frequency and phase of several controllers to avoid beat effect. Auto FM: Automatic frequency adjusting in real time to ensure best feeding result. Auto Speed Stabilization: Automatic feeding speed stabilizing in real time regardless of the quantities of the feeding parts. Auto Frequency Searching: Find the best operating frequency of the vibratory feeder and adjusts parameters automatically. Frequency Adjusting: Output Frequency ranges from 40.0Hz to 400.0Hz. Voltage Adjusting: Output Voltage ranges from 0V to 260V. Automatic Voltage Stabilizing: The controller can eliminate feeding speed variation caused by mains voltage fluctuation. Soft Startup: In order to avoid sudden shock to the work pieces, the controller can gently increase output voltage from 0 to the pre-set value when startup. Intelligent Photoelectric Sensing: Our adaptive Intelligent Photoelectric Sensor can help to stall the controller when work-pieces are full or work-piece is empty and to fulfill the functions of Soft Startup Time Setting,Startup Delay, Shutdown Delay, and Logical Relation Adjusting. Halt when Work-pieces are full: A NPN switch sensor can help to halt the controller when work-pieces are full and to fulfill the functions of Soft Startup Time Setting, Startup Delay, Shutdown Delay, and Logical Relation Adjusting. Acceleration: Due to this function, maximum output voltage value of the controller can be increased up to 150% of the input voltage value. Remote Speed Control: Output Voltage of the controller can be controlled by an external potentiometer, a PLC, or voltage control signal ranging form 1V to 5V. Controlling Output: The Controlling Output signal outgoing from the transistor can coordinate a solenoid or other external devices with the controller. Keypad Locking: Press the ON/OFF button and hold for 2 seconds to lock all buttons for fear of false operation. Maximum Output Restriction: Maximum Output Voltage value can be preset to protect the equipment from damage caused by misuse. Waveform Index Setting: Operators can weight efficiency and maximum capacity by adjusting this parameter. Default Settings Restonation: This function allows the user to restore all default parameter settings and reset the controller. Dimensions:190*53.6*94.5(L*W*H, mm) Weight: SDVC35-S:The controller weights 560g without accessory SDVC35-M:The controller weights 610g without accessory
  • Description

Model:SDVC35-S:1.5A   SDVC35-M:3.0A

Features:

Frequency Tracking: Synchronize output frequency and phase of several controllers to avoid beat effect.

Auto FM: Automatic frequency adjusting in real time to ensure best feeding result.

Auto Speed Stabilization: Automatic feeding speed stabilizing in real time regardless of the quantities of the feeding parts.

Auto Frequency Searching: Find the best operating frequency of the vibratory feeder and adjusts parameters automatically.

Frequency Adjusting: Output Frequency ranges from 40.0Hz to 400.0Hz.

Voltage Adjusting: Output Voltage ranges from 0V to 260V.

Automatic Voltage Stabilizing: The controller can eliminate feeding speed variation caused by mains voltage fluctuation.

Soft Startup: In order to avoid sudden shock to the work pieces, the controller can gently increase output voltage from 0 to the pre-set value when startup.

Intelligent Photoelectric Sensing: Our adaptive Intelligent Photoelectric Sensor can help to stall the controller when work-pieces are full or work-piece is empty and  to fulfill the functions of Soft Startup Time Setting,Startup Delay, Shutdown Delay, and Logical Relation Adjusting.

Halt when Work-pieces are full: A NPN switch sensor can help to halt the controller when work-pieces are full and  to fulfill the functions of Soft Startup Time Setting, Startup Delay, Shutdown Delay, and Logical Relation Adjusting.

Acceleration: Due to this function, maximum output voltage value of the controller can be increased up to 150% of the input voltage value.

Remote Speed Control: Output Voltage of the controller can be controlled by an external potentiometer, a PLC, or voltage control signal ranging form 1V to 5V.

Controlling Output: The Controlling Output signal outgoing from the transistor can coordinate a solenoid or other external devices with the controller.

Keypad Locking: Press the  ON/OFF button and hold for 2 seconds to lock all buttons for fear of false operation.

Maximum Output Restriction: Maximum Output Voltage value can be preset to protect the equipment from damage caused by misuse.

Waveform Index Setting: Operators can weight efficiency and maximum capacity by adjusting this parameter.

Default Settings Restonation: This function allows the user to restore all default

parameter settings and reset the controller.

Dimensions:190*53.6*94.5(L*W*H, mm)

Weight:

SDVC35-S:The controller weights 560g without accessory

SDVC35-M:The controller weights 610g without accessory

Front View




Bottom View


Signal Interface View

 vibration sensor

Technical Specifications:

Item

Value

Unit

Description

MIN

MAX

Input Power Voltage

85

260

V

AC RMS Vaule

Output Power Voltage

0

260

V

Less than 150% of Input Power Voltage

Output Current

0

1.5

A

SDVC31-S

0

3

SDVC31-M

Frequency Range

40

400

Hz



Output Power

0

330

VA

SDVC31-S

0

660

SDVC31-M

Output Waveform

Sine





Voltage Adjusting Accuracy

1

V



Frequency Adjusting Accuracy

0.1

Hz



Time Delay Range

0

20

s



Time Delay Accuracy

0.1

s



Soft Startup Time

0

10

s



Auxiliary Power Supply Voltage

22

26

V

24V DC Controlling Power Supply

Auxiliary Power Supply Current

0

200

mA

24V DC Controlling Power Supply

Standby Power Consumption

1.5

3

W



Display Method

5

digit

LED Digital Tube

Control Method

1-5

V

Remote Controlled Voltage

Standard TTL

Electric Level



Switching Signal

6 Buttons plus LED



Touch Button Keyboard

Ambient Temperature

-10

35

Non-condensing

Working Environment Humidity

10

85


Packing Photo
