sdvc14 Variable Voltage Digital Control Model for Vibratory Feeder SDVC14: 4A

  • sdvc14 Variable Voltage Digital Control Model for Vibratory Feeder
  • sdvc14 Variable Voltage Digital Control Model for Vibratory Feeder
Item Code:SDVC14: 4A Features:Features:1. Automatic Voltage Regulation: The built-in Digital Voltage Regulation function can eliminate feeding speed variation caused by mains voltage fluctuation.
  • Description

Features:

1、Automatic Voltage Regulation: Eliminate feed speed variation caused by mains voltage fluctuation .
2、Soft Startup: In order to avoid sudden shock to the feed material and vibratory feeder, the controller can gently increase output voltage from 0 to the preset value when startup.
3、Linear Voltage Control: Rotation angle of the voltage adjustment knob is linear with output voltage of the controller.
4、Overheat Protection: If internal temperature of the controller gets too high, the controller will stop its output to protect itself.
5、Overcurrent Protection: If output current exceeds its rated value by misoperation, the controller will stop its output to protect the controller and vibratory feeder.
6、Short-Circuit Protection: If output of the controller is short-circuited, the fuse inside the controller will be blown to protect the controller and vibratory feeder from further damage.

Dimensions: 102*63*27(L*W*H, mm)
Weight: The controller weights 92g without accessory

Front View



Technical Specifications:



Item

Range

Unit

Description

MIN

MAX

Input Voltage

150

260

V

AC RMS Value

Output Voltage

6

260

V

Less than Input Voltage

Output Current

0

4

A



Output Frequency

50/100

Hz

Mains Frequency is 50Hz

60/120

Hz

Mains Frequency is 60Hz

Output Waveform

Tangent Sine





Soft Startup Time

0.2

s



Response Time of Voltage Adjustment

0

0.02

s



Voltage Adjustment Accuracy

0

3

V

△Vin=10%

Work Space Temperature

0

40

Non-condensing

Work Space Humidity

10

85

ON/OFF Control Voltage

5

24

V
